The 551 model is positioned as “entry level” , although guaranteeing innovation and advanced performance. It is simpli ed but only where necessary, all for the bene t of pricing/competitiveness in the market. The inclination of each head, up to 22°30’ outwards, takes place via two circular guides positioned on four pairs of steel rollers. This solution, subject to patent, allows you to eliminate any cutting area obstruction, with the advantage of positioning and blocking the pro le and offers greater rigidity to traditional systems. Positioning via absolute magnetic band eliminates the necessity of the axes reference and connected cycle times.
Inclination of each head, up to 22°30' outwards for both the aluminium and PVC machine versions, is achieved on two circular guides mounted on four pairs of steel rollers. This patented solution makes it possible to eliminate obstructions in the cutting area, all to the benefit of profile positioning and clamping, while also offering greater rigidity than traditional systems. X axis absolute magnetic strip positioning eliminates the need for the axes reference and connected cycle times.
Making use of the ample space provided by the use of the virtual axis, clamping of the profile to be cut is performed by two horizontal hold-down devices with extreme precision and in absolute safely. For vertical clamping, particularly for special cuts, the machine can be equipped with a patented system of horizontal hold-down devices. Three mechanically operated intermediate supports deploy automatically to support the profile for very long cutting lengths.
The intuitively designed control panel allows correct mobile heads positioning in accordance with the required cutting schedule. The interface uses a 5.7” touch-screen and fully personalised software and is packed with bespoke functions that are unique to this machine. The control panel can be optionally installed on bearings sliding on a rail that spans the entire front of the machine. The machining cycle can be optimised by creating cutting lists, thereby reducing scrap and cycle times for parts loading-unloading.
The machine is prepared for the installation of a printer that can be selected from compatible models. The set-up includes software enabling for the label printing function, mechanical support elements for positioning on the machine, wiring and preparation for electrical connection, and a folding cover to protect the printer from shocks and possible entry of swarfs. The mechanical set-up for installation may vary according to the machine models.
