TKE 330 SA-MA en

TKE 330 SA-MA

home / product a to z / T

Troncatrice monotesta a lama ascendente prevista per tagli a 90°, 45° destro e sinistro ed angolazioni intermedie.

Estimate Request

Technical data

BLADE

Made of Widia (mm)

Ø = 300

BLADE FEED

Manual

CUTTING DIAGRAM

CUTTING AREA PROTECTION

Local, manually controlled

LUBRICATION SYSTEM

Manual

PROFILE POSITIONING

Manual workpiece reference stop

WORKPIECE LOCKING

Manual or pneumatic vertical vice (according to model)

1

Horizontal manual vice

1

MOTOR

Three-phase brakemotor

Brake intervention time (s)

10

Power (kW)

1,5

Included

Available

Cutting zone

The sturdy cast-iron horizontal support surface, with its vertical square rigidly coupled to it, forms the workpiece clamping area, which features a large bearing area for optimum clamping of workpieces.

TKE 330 SA-MA Cutting zone Tekna

TKE 330 SA-MA Blade Tekna

Blade

The cutting-off machine is equipped with a 300-mm cemented carbide blade mounted on a manually actuated feed system.

Vices

The machine is equipped with a horizontal and vertical vice assembly, which are pneumatically actuated in the S version, and manually actuated in the M version.

TKE 330 SA-MA Vices Tekna
