CSemi-automatic CNC cutting-off centre with horizontal blade feed, 2 controlled axes, designed for cutting profiles made of aluminium, PVC, light alloys in general. It performs automatic cutting according to predefined and optimized cutting lists. The machine is intended to perform cutting at an angle from 45° to 135° or from 22°30’ to 157°30’. It can be fitted with customised horizontal and vertical drilling units for specific automatic machining operations. The workpieces are machined in line. They are loaded from the feeder side and are to be unloaded manually on the opposite side.
The industrial label printer allows each cut profile to be identified with identifying features from the cutting list. In addition, barcode printing enables easy identification of the profile itself, which is particularly useful for subsequent machining steps on Machining Centres or assisted assembly lines.
