TKE  340 PA

Single-head, rising blade cutting-off machine, with left loading side, able to perform cuts from 15° left to 15° right and intermediate angles.

Technical data arrow_drop_down
BLADE
Made of Widia (mm)
Ø = 400
BLADE FEED
Pneumatic

CUTTING DIAGRAM
CUTTING AREA PROTECTION
Full guard manually operated

LUBRICATION SYSTEM
Spray-mist lubrication with oil emulsion

WORKPIECE LOCKING
Pair of pneumatic vertical vices

Optional additional horizontal vices
2
MOTOR
Three-phase (without brake)

Power (kW)
1,5
Rpm
2.800
Included
Available
Control
The control console allows user-friendly and intuitive machine operation. The practical lever with scale serves for rapid angular positioning of the blade. Instead, a further adjusting system allows adjustment of the vice pressure and blade outfeed rate.
Aluminum TKE 340 PA Control Tekna
Aluminum TKE 340 PA Vices Tekna
Vices
Thanks to the technical solutions adopted, the horizontal (optional for TKE 340 PA) and vertical vices ensure the utmost rigidity in workpiece clamping as well as rapid repositioning of the vices. Such characteristic allows the use of this machine in window/door manufacture.
Cutting zone
The rugged horizontal work bench associated with the vertical striker allows optimum positioning of the workpiece to be cut, thus ensuring considerable accuracy of the cut surface.
Aluminum TKE 340 PA Cutting zone Tekna
Aluminum TKE 340 PA Swarf drawer Tekna
Swarf drawer
A practical swarf drawer allows efficient collection of the processing debris thus ensuring clean conditions of the machine and work area.
