TKE  340 SD

Single head chop saw (downstroking cutting-off machine) with left loading side, rotation of the cutting head by 45° (to right and left) and manual tilting by 45° about the horizontal axis.

Technical data arrow_drop_down
BLADE
Made of Widia (mm)
Ø = 400
BLADE FEED
Pneumatic

CUTTING DIAGRAM
CUTTING AREA PROTECTION
Local, mechanically controlled

LUBRICATION SYSTEM
Micro-mist lubrication system with water and oil emulsion

WORKPIECE LOCKING
Pair of pneumatic horizontal vices

MOTOR
Three-phase brakemotor

Brake intervention time (s)
10
Power (kW)
2,2
Included
Available
Vices
The machine is equipped with horizontal vices assembly which, in the S version, are pneumatically actuated, while in the M version are manually actuated.
Aluminum TKE 340 SD Vices Tekna
Aluminum TKE 340 SD Cutting zone Tekna
Cutting zone
The sturdy cast-iron horizontal support surface, with its vertical square rigidly coupled to it, forms the workpiece clamping area; it features a large bearing surface for optimum clamping of workpieces.
Control
The manual actuator that characterises blade descent is equipped with a mechanical safety system aimed at preventing any accidental movement. At the same time, it determines the gradual exit of the blade itself. Angular positioning of the head is done by rotating the horizontal plane with mechanical snap lock for 45° (right and left) and manual locking for intermediate angles.
Aluminum TKE 340 SD Control Tekna
